Gigabyte A520M DS3H Micro-ATX AMD AM4 Motherboard

Gigabyte A520M DS3H Micro-ATX AMD AM4 Motherboard
Basic Information
Supported CPU AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
Type Dual-Channel Memory Architecture
Others Special FeaturesSupport for APP Center @BIOS EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer Support for Q-Flash Plus Support for Q-Flash Support for Xpress Install
BIOS 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm
Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel
External Features
Expansion Slots PCI CPU: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 Chipset: 2 x PCI Express x1 slots, supporting PCIe 3.0 (PCIEX1_1, PCIEX1_2) M.2 Socket 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
Technical Specification
Memory 3rd Gen AMD Ryzen with Radeon Graphics processors: Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules Maximum Memory 128 GB (32 GB single DIMM capacity) Graphics Graphics 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz Support for up to 3 displays at the same time
Chipset
Chipset Model AMD A520
Memory
Slots 4 x DDR4 DIMM
Supported Memory 3rd Gen AMD Ryzen Processors: Support for DDR4 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz
Graphics
Max Shared Memory 16 GB
Ports & Slots
Internal I/O Ports 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x serial port header 1 x Clear CMOS jumper 1 x Q-Flash Plus button
LAN Port (s) Realtek GbE LAN chip (1000 Mbit/100 Mbit)
Supported Storage CPU: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support) Chipset: 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10
TPM (Trusted Platform Module) 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
USB (s) CPU: 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB header 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
HDMI Port 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz Display Port (s) 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz DVI-D (s) 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
Warranty Information
Warranty 3 Years

The Gigabyte A520M DS3H Micro-ATX AMD AM4 Motherboard is a dependable and budget-friendly platform designed for AMD Ryzen processors. Supporting 3rd Gen Ryzen and Ryzen 5000 Series CPUs, this motherboard delivers stable performance for everyday computing, home builds, and office PCs. It features dual-channel DDR4 memory support, PCIe Gen3, NVMe M.2 storage, and Ultra Durable components for long-term reliability. With its compact Micro-ATX form factor, the A520M DS3H is ideal for space-efficient builds without sacrificing essential features.


Write a review

Please login or register to review

Model: Gigabyte A520M DS3H Ultra Durable

  • AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
  • Ultra-Fast NVMe
  • RGB FUSION 2.0 Supported
  • 5+3 Phases Pure Digital VRM
Gigabyte A520M DS3H Micro-ATX AMD AM4 Motherboard
..

Key Features

Model: Gigabyte A520M DS3H Ultra Durable

  • AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
  • Ultra-Fast NVMe
  • RGB FUSION 2.0 Supported
  • 5+3 Phases Pure Digital VRM
Based on 0 reviews. - Write a review
10,300.00৳
  • Stock: In Stock
  • Model: Gigabyte A520M DS3H Ultra Durable
