Gigabyte H310M S2H 9th Gen Micro ATX Motherboard

Gigabyte H310M S2H 9th Gen Micro ATX Motherboard
Gigabyte H310M S2H 9th Gen Micro ATX Motherboard
Gigabyte H310M S2H 9th Gen Micro ATX Motherboard
Gigabyte H310M S2H 9th Gen Micro ATX Motherboard
Basic Information
Supported CPU Support for 9th and 8th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package L3 cache varies with CPU
Type DDR4
BIOS 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor Micro ATX Form Factor; 22.6cm x 18.5cm
Graphics Card 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz * Support for HDMI 1.4 version and HDCP 2.2. Max Shared Memory 1 GB
Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
External Features
PCI 1 x PCI Express x16 slot, running at x16 (The PCIEX16 slot conforms to PCI Express 3.0 standard.) 2 x PCI Express x1 slots (The PCI Express x1 slots conform to PCI Express 2.0 standard.)
Chipset
Chipset Model Intel H310 Express Chipset
Memory
Slots 2 x DIMM sockets
Others
Bundled Software Norton Internet Security (OEM version)
Special Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS AutoGreen Cloud Station EasyTune Fast Boot Game Boost ON/OFF Charge Platform Power Management Smart Backup Smart Keyboard Smart TimeLock Smart HUD System Information Viewer USB Blocker V-Tuner Support for Q-Flash Support for Xpress Install
Connectivity
HDMI 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz Support for HDMI 1.4 version and HDCP 2.2. D-Sub (s) 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz DVI-D (s) 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz The DVI-D port does not support D-Sub connection by adapter.
Connector
M.2 Socket 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x2 SSD support)
Ports & Slots
Internal I/O Ports 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.1 Gen 1 header 1 x USB 2.0/1.1 header 1 x Clear CMOS jumper TPM (Trusted Platform Module ) 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
LAN Port (s) Realtek GbE LAN chip (10/100/1000 Mbit)
Supported Storage 4 x SATA 6Gb/s connectors
USB (s) 4 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
Warranty Information
Warranty 03 Years

The Gigabyte H310M S2H 9th Gen Micro ATX Motherboard is designed for Intel 8th and 9th Gen processors, offering reliable performance with DDR4 memory support, high-speed connectivity, and essential expansion slots. Its compact Micro-ATX form factor makes it ideal for budget-friendly desktop builds, delivering stability and efficiency for everyday computing.


Write a review

Please login or register to review

Model: H310M S2H

  • Supports 9th and 8th Gen Intel Core Processors
  • Chipset: Intel H310 Express Chipset
  • 2 x DIMM, Max. 32GB DDR4
  • 3 x PCIe slots
Gigabyte H310M S2H 9th Gen Micro ATX Motherboard
..

Key Features

Model: H310M S2H

  • Supports 9th and 8th Gen Intel Core Processors
  • Chipset: Intel H310 Express Chipset
  • 2 x DIMM, Max. 32GB DDR4
  • 3 x PCIe slots
