| Basic Information | |
| Supported CPU | Supports 14th Gen, 13th & 12th Gen and next-gen Intel Core Processors (LGA1700) Supports Intel Hybrid Technology Supports Intel Turbo Boost Max 3.0 Technology Supports Intel Thermal Velocity Boost (TVB) Supports Intel Adaptive Boost Technology (ABT) |
| BIOS | 128Mb AMI UEFI Legal BIOS with GUI support |
| Form Factor | Micro ATX Form Factor: 9.6-in x 7.9-in, 24.4 cm x 20.1 cm |
| Audio | HD Audio Jacks: Line in / Front Speaker / Microphone |
| Chipset | |
| Chipset Model | Intel B760 |
| Memory | |
| Maximum Memory | 64GB |
| Slots | 2 |
| Type | DDR4 |
| Bus Speed | Dual Channel DDR4 Memory Technology Supports DDR4 non-ECC, un-buffered memory up to 5333+(OC) Supports ECC UDIMM memory modules (operate in non-ECC mode) Supports Intel Extreme Memory Profile (XMP) 2.0 1DPC 1R Up to 5333+ MHz (OC), 3200 MHz Natively. 1DPC 2R Up to 4400+ MHz (OC), 3200 MHz Natively. |
| Others | |
| Bundled Software | Software - ASRock Motherboard Utility (A-Tuning) - ASRock XFast LAN UEFI - ASRock EZ Mode - ASRock Full HD UEFI - ASRock My Favorites in UEFI - ASRock Auto Driver Installer - ASRock Instant Flash - ASRock Easy RAID Installer |
| Special Features | Rock-Solid Durability - 5+1+1 Power Phase EZ Update - ASRock Auto Driver Installer |
| Connector | |
| PCI-E | CPU: - 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode* Chipset: - 2 x PCIe 3.0 x1 Slots (PCIE2 and PCIE3)* - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module |
| Network & Connectivity | |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| Ports & Slots | |
| D-Sub (s) | 1 x D-Sub |
| Display Port (s) | 1x DisplayPort |
| Internal I/O Ports | 1 x Chassis Intrusion and Speaker Header 1 x CPU Fan Connector (4-pin) 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) 2 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector 1 x Front Panel Audio Connector 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) |
| LAN Port (s) | Gigabit LAN 10/100/1000 Mb/s Realtek 8111H |
| Supported Storage | CPU: - 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* Chipset: - 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2260/2280 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modes* - 4 x SATA3 6.0 Gb/s Connectors |
| TPM (Trusted Platform Module) | 1 x SPI TPM Header |
| USB (s) | 1 x USB 3.2 Gen1 Type-C (Rear) 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front) 5 x USB 2.0 (2 Rear, 3 Front) * All USB ports support ESD Protection |
| HDMI Port | 1x HDMI |
| Warranty Information | |
| Warranty Details | 3 years |
ASRock B760M-HDV/M.2 D4 Motherboard - Optimized for Intel DDR4 Systems
The ASRock B760M-HDV/M.2 D4 is a compact and high-performance Micro ATX motherboard tailored for Intel 12th and 13th Gen processors. With DDR4 memory support, ultra-fast M.2 storage, and advanced connectivity, this motherboard is ideal for efficient builds, from productivity-focused systems to entry-level gaming rigs.
The ASRock B760M-HDV/M.2 D4 offers a great balance of features, reliability, and affordability. Its advanced memory, storage, and connectivity options make it a perfect choice for modern computing needs, whether for work or leisure.
Upgrade your build with the ASRock B760M-HDV/M.2 D4 Motherboard and enjoy a smooth, efficient, and future-ready computing experience
